In the blister plastic packaging industry, this plastic clicker press is very popular, it also called hydraulic cutting machine. It is responsible for cutting this link.
Compared to ordinary cutting presses, our plastic clicker press is equipped with a mechanical hand pick-up device, which is also a unique patent independently developed by our company.
It greatly reduces labor costs and improves production efficiency.
1. Parameter:
Model. No | Pressure | Dimension | Cutting Area | Motor Power | Stroke | Net Weight |
HG- B60T | 60 T | 3000*2300*1570mm | 810*1400mm | 5.5kw | 50-230mm | 4500kg |
HG- B80T | 80 T | 3000*2300*1570mm | 810*1400mm | 7.5kw | 50-230mm | 5000kg |
HG- B100T | 100 T | 3000*2300*1570mm | 810*1400mm | 7.5kw | 50-230mm | 5500kg |
HG- B120T | 120 T | 3000*2300*1570mm | 810*1400mm | 11kw | 50-230mm | 6300kg |
HG- B150T | 150 T | 3000*2300*1570mm | 810*1400mm | 11kw | 50-230mm | 7000KG |
2. Application:
This packaging blister plastic clicker press is very popular in our country, the machine widely used in the plastics industry.
Use for die-cutting PVC/ PET/ PE/ PS tray packaging blister, such as cup cover, fresh/seafood tray, food container, cup cover, fruit box, etc.
3. Feature:
1. Double automatic working tables, increases the output twice or triple.
2. Controlled by PLC(Programmable Logic Controller), with touching screen, to set and micro-adjust working pressure, cutting depth, feeding speed easier, faster, and more precise.
3. Powered by a hydraulic system, slow down when the cutting die touches material, to confirm the precision between upper and bottom for thick materials
4. The Auto-balance structure of double-cylinder, four-column, and self-balance connecting rod make sure equal pressure in any working area.
5. The Central automatic lubrication system increases machine durability, prolong the plastic clicker press working time.
4. Picture:
